Special Report


       able for an SCC condition assessment   potential (CIP),  pipeline current  the material properties, and the resul-
       can be summarized as follows:        mapping, and soil resistivity mea-  tant tolerable SCC size.
          Single SCC features that fail can be   surements are conducted.
          characterised entirely as to the failure  3.  Direct examination – pipe is veri-  Some analytical models allow for a
          pressure,  pipe material properties,   fi ed  for  the  above-ground  survey  determination of the mode of failure for
          physical SCC dimensions, and inter-  results and physical inspection  of  the SCC feature – a leak or a rupture. At
          action.                           the pipe coating, pipe surface, and  pressures associated with both normal
          A  minimum failure pressure  for   soil electrolytes.          operation and higher pressures for SCC
          SCC features  can  be calculated  4.  Post-assessment – results gathered in  pressure testing, the metal  ligament
          for the remaining pipe segment by   steps 1, 2, and 3 are integrated for an  joining the tip of the SCC feature (in
          assuming that the most severe feature   overall integrity assessment, valida-  the depth direction) and the inner pipe
          has failed; however, this pressure is   tion of the external ECDA process,  wall will typically fail in a ductile man-
          typically at or below the operating   and determination of the interval  ner, momentarily creating  a through-
          pressure.                         period to repeat the ECDA process.  the-wall feature.
          The  quantity, density, and location
          of SCC features that do not fail  Condition assessment of SCC severity  Axial propagation of the resultant
          within a  pipe segment remains   The severity of individual SCC fea-  leak may or may not occur, depending
          unknown.                       tures is defi ned by the calculated failure  on the axial  length of the leak, the
          Probably the  largest source of  pressure of that feature. The minimum  applied stress, and the toughness of the
          uncertainty  is the assumed crack  SCC failure pressure for a pipe seg-  steel. However,  axial propagation is
          growth rate.  However, errors also  ment can be directly determined from  typical of SCC features of the genera-
          can be introduced from the calcu-  the failure pressure of an SCC feature  tion of pipe where SCC has been identi-
          lations of the crack sizes.  To be  failing during an SCC pressure test or  fi ed, resulting in a rupture as the normal
          conservative, it is important not to  in-service failure.       mode of failure.
          underestimate the size of the most
          signifi cant  surviving  fl aw  and  not   In addition, failure pressures can  SCC mitigation methods
          to overestimate the size of a critical  be calculated  from measurements   There are many SCC  prevention
          fl aw at operating pressure(7, 8).  obtained at an excavation of the pipe-  methods  available in the industry.
                                         line where SCC has been documented  However, the current article highlights
       SCC condition assessment methodo-  or from SCC ILI data  where features  the most popular methods(7, 8).
       logies                            have been identifi ed (8).
          External  Corrosion Direct  Assess-                             Coatings
       ment (ECDA) methodology is men-   SCC in association with other features  Inadequate coating performance is
       tioned in the NACE International stan-  The accuracy of the failure pressure  the central contributor to pipeline SCC
       dard practice  SP05021 for integrity  calculation  is dependent on the accu-  susceptibility.  The pipeline company
       assessment of external corrosion threats  racy of the calculation of stress, which  should emphasize coating procedures so
       on buried pipelines. This methodology  infl uences  the  SCC  feature.  For  SCC  that future coating failure susceptibility,
       can be used in combination or separately  interacting with other integrity defects,  especially disbondment, is minimized.
       with NACE SP02042 on SCC direct  the interacting defect should  be con-  When selecting the appropriate coat-
       assessment methodology.           sidered the primary integrity threat and  ing material, a balance between perfor-
                                         managed with the appropriate detection  mance and application constraints must
          The NACE ECDA protocol is a  and mitigation methods for this defect.  be considered.  The pipeline company
       four-step process:                However, the discovery of SCC within  must know the exposure conditions the
       1.  Pre-assessment – pipeline’s physi-  these features may require an increase  pipeline coating will face and the practi-
          cal characteristics, operating his-  in the risk of the interacting feature.  cal challenges when applying a coating
          tory, and prior inspections  are                                for long-term performance.
          documented.                    SCC failure pressure calculations
       2.  Indirect  inspection – conducting   There are several analytical models   Coatings should possess the follow-
          complementary above-ground fi eld  available  for determining  SCC failure  ing performance characteristics:
          surveys like direct current voltage  pressures.  These methods rely on the
          gradient (DCVG), close interval  relationship between the applied stress,   Adhesion: Materials with good ad-
